- Operation: three stages;
- Emission class: Low NOx class 2 (<185 mg/kWh) according to EN267
Technologies
WORKING DIAGRAM
TECHNICAL DATA
| Minimum power output (kW) | 260 |
| Maximum power output (kW) | 950 |
| Fan motor (kW) | 1.5 |
| Protection level | IP21 |
OTHER AVAILABLE CONFIGURATIONS
- Versions for continuous ventilation and post-ventilation
OVERALL DIMENSIONS
| A | B | C | D | E | F | G | H | I | J | Øa | Øb | c | d |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 581 | 549 | 752 | 450 | 99 | 164 | 170 | KN: 215 / KM: 325 / KL: 435 | 230X238 | 950 | 195 | 220-260 | M10 | 45° |
